TMT BAR SIZES :
SPECIFICATION OF TMT BARS WEIGHTS (Kg/Mtr) SIZE IS-1786:2008 Simhadri TMT Std Min Max Min Max 8mm 0.395 0.367 0.423 0.387 0.399 10mm 0.617 0.574 0.660 0.605 0.623 12mm 0.888 0.844 0.932 0.870 0.897 16mm 1.578 1.499 1.657 1.546 1.594 20mm 2.466 2.392 2.540 2.417 2.491 25mm 3.854 3.738 3.970 3.777 3.893 28mm 4.835 4.690 4.980 4.738 4.883 32mm 6.316 6.127 6.505 6.190 6.379 MECHANICAL PROPERTIES OF TMT BARS IS SPECIFICATION FOR TMT BARS
SPECIFICATION OF TMT BARS CHEMICAL PROPERTIES (%) Parameter IS-1786:2008 Simhadri TMT Fe-415 Fe-500 Fe-500D Fe-415 Fe-500 Fe-500D HSCRM Yield Stress(N/mm2) 415 500 500 430-490 520-560 520-560 520-580 Ultimate Tensile Strength (N/mm2) 485 545 565 500-560 600-680 600-680 600-690 Elongation(%) 14.5 12 16 20-25 18-24 18-24 18-24 Total Elongation @ Max Force(%) - - 5 - - 8-10 8-10 Ration (UTS/YS) 1.16 1.09 1.13 1.15-1.25 1.13-1.22 1.14-1.25 1.18-1.25 SEIL CHEMICAL COMPOSITION FOR TMT BARS
SPECIFICATION OF TMT BARS CHEMICAL COMPOSITION (%) Parameter IS-1786:2008 Simhadri TMT Fe-415 Fe-500 Fe-500D Fe-415 Fe-500 Fe-500D HSCRM Carbon (C) 0.3 0.3 0.25 0.18 - 0.25 0.18 - 0.23 0.16 - 0.22 0.18 - 0.22 Sulphur (S) 0.060 0.055 0.040 0.035-0.055 0.025-0.050 0.020-0.035 0.025-0.045 Phosphorus (P) 0.060 0.055 0.040 0.035-0.055 0.035-0.050 0.025-0.035 0.035-0.050 Sulphur + Phosphorus(S+P) 0.110 0.105 0.075 0.070-0.11 0.060-0.100 0.045-0.070 0.060-0.095 Carbon Equivalent (CE) 0.42 0.42 0.42 0.26-0.37 0.26-0.35 0.26-0.32 0.30-0.45 Chromium(Cr) 0.40-0.65 Copper(Cu) 0.20-0.30 Corrosion Resistance Element(P+Cr+Cu) 0.75 HSCRM
PHYSICAL PROPERTIES
standard grade Yeild Strength (N/mm2) min UTS (N/mm2) min UTS (N/mm2) min IS - 1786-2008 Fe - 500 500 565 12-18 IS - 1786-2008 Fe - 500d 500 565 16-20 CHEMICAL PROPERTIES
IS 1786-2008 C S p S&P; CE FE 500 0.30 MAX 0.055 MAX 0.055 MAX 0.105 MAX 0.42 MAX Fe - 500d 0.25 MAX 0.040 MAX 0.040 MAX 0.075 MAX 0.42 MAX
